We are a leading manufacturer specializing in high-density multilayer printed circuit boards and specialty boards. With certifications including UL, ISO9001:2015, ISO14001:2015, CQC, IATF16949:2016, and "National Military Standard," we provide top-quality products and services. Our extensive product range includes multilayer boards, impedance boards, high-frequency boards, high TG thick copper foil boards, 5G high-speed boards, buried blind via boards, aluminum-based boards, hybrid dielectric boards, HDI, rigid-flex boards, specialty boards, and customized solutions.
Driven by technological innovation, our products are widely used in industries such as communication equipment, industrial control, automotive electronics, energy and power, medical devices, IoT, research institutions, aerospace, and defense. With over 19 years of experience, we have served over 1,000 technology innovation-oriented enterprises with rapid prototyping and mass production services. We are committed to delivering cutting-edge solutions and exceeding customer expectations in the dynamic electronics industry.
The product features eight parameter options. Please refer to the specific configuration details below for your requirements and quote inquiry:
| Category | Volume Production | Sample Processing |
|---|---|---|
| Layer Count | 1-68L | 64 Layer |
| Max Thickness | 10mm (394mil) | 14mm (551mil) |
| Min Line Width/Space (Inner Layer) | 2.2mil / 2.2mil | 2.0mil / 2.0mil |
| Min Line Width/Space (Outer Layer) | 2.5 / 2.5mil | 2.2 / 2.2mil |
| Alignment Capability (with Core Board) | ±25um | ±20um |
| Inner Layer Alignment | ±5mil | ±4mil |
| Max Copper Weight | 6oz | 30oz |
| Holes Size (Mechanical Drilling) | ≥0.15mm (6mil) | ≥0.1mm (4mil) |
| Holes Size (Laser Drilling) | 0.1mm (4mil) | 0.050mm (2mil) |
| Max Size (Unit Size) | 850mm x 570mm | 1000mm x 600mm |
| Max Size (Panel Size) | 1250mm x 570mm | 1320mm x 600mm |
| Aspect Ratio (Unit Size) | 20:1 | 28:1 |
| Aspect Ratio (Panel Size) | 25:1 | 35:1 |
| Lead-Free / Halogen-Free Materials | EM827, 370HR, S1000-2, IT180A, EM825, IT158, S1000 / S1155, R1566W, EM285, TU862HF | |
| High-Speed PCB Material | Megtron6, Megtron4, Megtron7, TU872SLK, FR408HR, N4000-13 Series, MW4000, MW2000, TU933 | |
| High-Frequency PCB Material | Ro3003, Ro3006, Ro4350B, Ro4360G2, Ro4835, CLTE, Genclad, RF35, FastRise27 | |
| Other Materials | Polyimide, Tk, LCP, BT, C-ply, Fradflex, Omega, ZBC2000 | |
| Surface Finished | HAL, HAL-LF, ENIG, IMMERSION TIN, OSP, IMMERSION SILVER, GOLD FINGER, Hard Gold/Soft Gold Plating | |
| Special Technology | Blind & buried holes, Via in pad, Semi-plating holes, Counterbore, Step mounting holes, Drill Mixed RF PCB, Busbar PCB | |
Actual conditions are subject to confirmation prior to production.
As PCBs are highly customized products, returns are not supported. For verified quality issues, please contact customer support for a refund or replacement options. We do not bear any losses or costs beyond the product value. Delays in delivery due to force majeure factors (such as power outages or water supply interruptions) will not be eligible for compensation.
Please communicate directly with customer support to confirm any special instructions before ordering; do not leave unattended messages as we are not responsible for missed communications. Before and after payment, please confirm the technical process details, quantity, and layers. Problems arising after production starts or after shipment will not be eligible for refunds. Please confirm specifications with your engineer beforehand.
Orders placed before 17:00 are calculated as placed on the same day; orders placed after 17:00 are calculated as placed the next day. "24-hour delivery" refers to one business day, not literal 24 hours. The delivery times provided do not include Sundays or public holidays.
Standard process details include: green solder mask, white silkscreen, 1.6mm board thickness, HASL surface finish, 1oz copper weight, vias with solder mask coverage, minimum line width/spacing of 0.2mm, and vias above 0.3mm. Gerber formats are verified according to files provided. Special process configurations require updated quotes.
We support international shipping with the following flexible options to meet your deadline and budget needs:
| Layer Count | Sample Shortest Lead Time | Sample Standard Lead Time | Mass Production Lead Time |
|---|---|---|---|
| 2 layer | 24 hours | 3 days | 6-7 days |
| 4 layer | 36 hours | 5 days | 8-10 days |
| 6 layer | 48 hours | 5 days | 8-12 days |
| 8 layer | 72 hours | 5 days | 9-12 days |
| 10 layer | 4 days | 7 days | 14 days |
| 12 layer | 4 days | 7 days | 16 days |
| 14 layer | 5 days | 8 days | 16 days |
| 16 layer | 5 days | 9 days | 18 days |
| 18 layer | 7 days | 10 days | 18 days |
| 20 layer and above | To be negotiated | To be negotiated | To be negotiated |
RS-274-X, RS-274-D, CAD, DXP, Protel 99 SE, PADS, GC-CAM formats accepted for analysis.
What types of specialized PCBs are you capable of manufacturing?
We specialize in multilayer boards (up to 68 layers), high-frequency boards, impedance boards, thick copper foil boards, HDI, rigid-flex boards, 5G high-speed boards, and custom specialty solutions.
What is the shortest lead time for prototype samples?
For double-layer PCBs, the shortest sample lead time is 24 hours. For 4-layer and 6-layer PCBs, the shortest sample lead times are 36 hours and 48 hours respectively, subject to confirmation.
Which file formats do you accept for engineering and manufacturing?
We support standard CAD/CAM and Gerber formats, including RS-274-X, RS-274-D, CAD, DXP, Protel 99 SE, PADS, and GC-CAM files.
What quality assurance standards do you follow?
Our operations are strictly managed under systems including ISO 9001, ISO 14001, IATF16949, RoHS, Reach, UL, and CQC. We check shipping acceptance based on standard IPC guidelines.
What is the policy for order cancellations, returns, or exchanges?
Because printed circuit boards are custom products, returns are not accepted. For quality issues, customer support can process refunds or replacements up to the product value. Confirm parameters before payment.
What global shipping methods are available?
We support air express shipping options (UPS, DHL, TNT, CTS, FEDEX), railway freight shipping, ocean shipping, or shipping through customer-designated carrier methods.
