FPC Flexible PCB Module Keyboards 1-2layer Custom Manufacturer Polyimide Consumer Electronic OEM ODM

Product Description

About Us

We are a leading manufacturer specializing in high-density multilayer printed circuit boards and specialty boards. With certifications including UL, ISO9001:2015, ISO14001:2015, CQC, IATF16949:2016, and "National Military Standard," we provide top-quality products and services. Our extensive product range includes multilayer boards, impedance boards, high-frequency boards, high TG thick copper foil boards, 5G high-speed boards, buried blind via boards, aluminum-based boards, hybrid dielectric boards, HDI, rigid-flex boards, specialty boards, and customized solutions. Driven by technological innovation, our products are widely used in industries such as communication equipment, industrial control, automotive electronics, energy and power, medical devices, IoT, research institutions, aerospace, and defense. With over 19 years of experience, we have served over 1,000 technology innovation-oriented enterprises with rapid prototyping and mass production services. We are committed to delivering cutting-edge solutions and exceeding customer expectations in the dynamic electronics industry.

Main Products

High-density Multilayer PCB
Impedance Control PCB
High Frequency PCB Board
Specialty PCB Board
Rigid-Flex PCB Solution
Thick Copper PCB
HDI PCB Board
Buried Blind Via PCB
Customized Specialty Board

Production Line and Equipment

Automated Production Facility
Drilling Equipment
Precision Exposure Machine
Advanced Manufacturing Process
Lamination System
AOI Inspection Station
Surface Finish Line
Plating Tanks
V-Cut & Routing Facility

Manufacturing Technique

Rigid PCB Manufacturing Capability
Category Volume Production Sample Processing
Layer Count 1-68L 64 Layer
Max Thickness 10mm (394mil) 14mm (551mil)
Min Line Width/Space (Inner) 2.2mil/2.2mil 2.0mil/2.0mil
Min Line Width/Space (Outer) 2.5/2.5mil 2.2/2.2mil
Alignment with Core Board ±25um ±20um
Inner Layer Alignment ±5mil ±4mil
Max Copper Thickness 6oz 30oz
Min Hole Size (Mechanical) ≥0.15mm (6mil) ≥0.1mm (4mil)
Min Hole Size (Laser) 0.1mm (4mil) 0.050mm (2mil)
Max Unit Size 850mm X 570mm 1000mm X 600mm
Max Panel Size 1250mm X 570mm 1320mm X 600mm
Aspect Ratio (Unit) 20:1 28:1
Aspect Ratio (Panel) 25:1 35:1
Lead-Free / Halogen-Free Materials EM827, 370HR, S1000-2, IT180A, EM825, IT158, S1000 / S1155, R1566W, EM285, TU862HF
High-Speed Materials Megtron6, Megtron4, Megtron7, TU872SLK, FR408HR, N4000-13 Series, MW4000, MW2000, TU933
High-Frequency Materials Ro3003, Ro3006, Ro4350B, Ro4360G2, Ro4835, CLTE, Genclad, RF35, FastRise27
Other Special Materials Polyimide, Tk, LCP, BT, C-ply, Fradflex, Omega, ZBC2000
Surface Finishes HAL, HAL-LF, ENIG, Immersion Tin, OSP, Immersion Silver, Gold Finger, Hard/Soft Gold Plating
Special Technologies Blind & Buried Holes, Via in Pad, Semi-plating Holes, Counterbore, Step Mounting Holes, Mixed RF PCB, Busbar PCB

Quality Assurance

  • Strict adherence to the Quality Management System to ensure each product meets high-quality requirements.
  • Operated under ISO 9001, ISO 14001, IATF16949, RoHS, REACH, UL, and CQC quality management standards, running IATF 16949 simultaneously.
  • Complete staff involvement across all production stages for end-to-end process control.
  • Ultimate goal of ensuring 100% quality reliability on delivery.
  • Shipping acceptance criteria: Complies strictly with customer requirements and IPC standards.
  • Cooperating with customer experiments to improve product performance and assist in setting high-quality specifications.

Laboratory Capabilities

Lab Test Equipment
Reliability Testing Laboratory
Metallographic Analysis
Impedance Measurement Device
Chemical Analysis Equipment

Packing & Shipping

Secure Packing Process

Shipping Standards

We ship PCB orders via the following options:
1. Air shipment (UPS, DHL, TNT, CTS, and FEDEX)
2. Railway transport
3. Seaborne transport
4. Customer Designated Shipping Method

Layers Sample Shortest Lead Time Sample Standard Lead Time Mass Production Lead Time
2 layer 24 h 3 days 6-7 days
4 layer 36 h 5 days 8-10 days
6 layer 48 h 5 days 8-12 days
8 layer 72 h 5 days 9-12 days
10 layer 4 days 7 days 14 days
12 layer 4 days 7 days 16 days
14 layer 5 days 8 days 16 days
16 layer 5 days 9 days 18 days
18 layer 7 days 10 days 18 days
20 layer and above To be negotiated To be negotiated To be negotiated
Vacuum PCB Packaging
Carton Box Packing for Shipment

High Efficiency Team

Professional Engineering Team
  • 24h technical support
  • 24h Gerber files handling
  • Complete EQ within 4-8 hours
  • Support for up to 400 new project engineering reviews
Accepted CAD/CAM Gerber File Formats
  • RS-274-X & RS-274-D CAD
  • DXP, Protel 99 SE
  • PADS, GC-CAM
Professional Manufacturing Team
  • All processes operating 24 hours daily
  • Monthly production of over 10K high-mix part numbers
  • More than 100 QTA (Quick Turnaround) orders processed daily
  • Comprehensive one-step service from prototype to mass production
Efficient Order Operation Center
  • 24-hour rapid customer support response
  • Quotations processed and sent within 4 hours

Certifications

Company Certifications

Frequently Asked Questions

What types of PCB products do you manufacture?
Our product range includes high-density multilayer boards, impedance control boards, high-frequency boards, high TG thick copper boards, 5G high-speed boards, buried blind via boards, aluminum-based boards, hybrid dielectric boards, HDI, rigid-flex boards, and customized specialty boards.
What certifications do your manufacturing facilities hold?
Our manufacturing facilities and processes hold key industry certifications, including UL, ISO 9001:2015, ISO 14001:2015, CQC, IATF 16949:2016, and the National Military Standard. We also comply with RoHS and REACH requirements.
What raw materials do you support for fabrication?
We support a wide array of premium materials. This includes lead-free/halogen-free substrates (like EM827, 370HR, S1000-2, IT180A), high-speed materials (such as Megtron6, Megtron4, Megtron7, TU872SLK), high-frequency materials (like Ro3003, Ro4350B, Ro4835), and specialty elements (Polyimide, LCP, BT, and C-ply).
What are the shortest lead times for PCB samples?
We offer rapid prototyping services. The shortest sample lead times are 24 hours for 2-layer PCBs, 36 hours for 4-layer PCBs, 48 hours for 6-layer PCBs, and 72 hours for 8-layer PCBs. Larger multilayer configurations are subject to direct negotiation.
What CAD/CAM file formats do you accept?
Our engineering support team accepts and works with standard design formats including RS-274-X, RS-274-D, CAD, DXP, Protel 99 SE, PADS, and GC-CAM.
What shipping methods do you offer for orders?
We support multiple dispatch options to accommodate your requirements: standard express air shipping (UPS, DHL, TNT, CTS, and FEDEX), railway freight, seaborne cargo, or any other customer-designated shipping methods.
